Surfboard design feature, usually consisting of four or six longitudinal bevels in the rear half of the board's underside, thought to increase board speed by directing water toward the tail.

Jim Pollard, Australian surfboard shaper from the Sunshine Coast of Queensland, produced one of the first channel bottom boards in 1974; Pollard's "beetail" featured four elliptical sets of channels—eight channels total, four on either side of the board's centerline. New South Wales surfer Col Smith introduced a modified version of the channel bottom in 1977, optimistically calling his six-channel boards "as significant a breakthrough as shortboards and lightweight materials were a few years ago."

But it was New Zealand-born shaper Allan Byrne who really brought the channel bottom to the attention of the surf world, shaping them for top Australian pros like Wayne Bartholomew and Gary Elkerton, and adapting the design to the tri-fin in 1982. On "soft" channel bottoms, the slot edges are rounded and the channels blended into the flat bottom surface near the tail. "Hard" channel bottoms, as developed by Byrne, cut up to a half-inch into the bottom of the board, forming table-edge ridges that run all the way to the end of the tail. Both versions are time-consuming and expensive to build, and neither caught on with the surfing public at large.

Channel bottom boards for the most part are used in larger surf, although a four-channel design, introduced in 2000 to critical praise (but low sales), has been used in smaller waves as well. Concave bottom boards, on the other hand, while similar in theory to the channel bottom, met with far greater success, and became a standard design on most shortboards in the mid-'90s.

channel bottom
